Bto30 HDG Spiral Razor Wire Concertina CE Certified

AN PING XI RUN METAL MESH CO.,LTD
Contact Now

Bto30 HDG Spiral Razor Wire Concertina CE Certified

  • 1
  • 2

Brand Name : XR

Model Number : WRW

Certification : CE

Place of Origin : CHINA

MOQ : 6 Square Meters

Price : Negotiated

Payment Terms : T/T, L/C, Western Union, MoneyGram

Supply Ability : 500 Tons Per Month

Delivery Time : 7-10 days after get the payment

Packaging Details : Pallet

Name : Bto30 HDG Spiral Razor Wire Concertina CE Certified

Zinc Coated : Galvanized Wire:8-60g/m2;Blade:40-60g/m2 Or As Customer's Req

Material : Galvanized And Stainless Steel

Mesh Aperture : 75x150Mm

Panel Size : 1x2M,2x4M,4x8M

Barb Length : BTO10 12 18 22 28 30 CBT60 65

Height : 1.2/1.5/1.8/2.1/2.4M

Application : Security And Safety

Contact Now

Welded Razor Wire/Straight Razor Wire/Flat Razor Wire And Certina Or Spiral Razor Wire

Welded razor wire

Diamond welded mesh straight razor wire gives people a kind of unique feeling. There are various mesh openings, generally the mesh openings are 70 × 150 mm and 100 × 150 mm, and this razor wire is often manufactured with frame for fixing function. Mesh razor wire's tape is sharp, fingers will be cut quickly, so this wire mesh is anti climb, and can greatly prevent the behaviors of greedy people to stop the crime. Welded razor wire is often combined with the concertina razor wire to achieve high level security and used by military fighters for army fencing, frontier fencing or some strict organizations fencing.

Straight razor wire

The material of straight razor wire can only be galvanized steel wire, so anti-corrosion effect is better. Packaging method is as same as the barbed wire, it can be pulled into a straight line and it's easy to install. According to different purposes of customers, there are various ways to install. It can not only save money for customers but also anti-theft. It can be used individually, and also can be used with other fences. It's mainly applicable to residential area, storage room, coal mine base, farming site, also used for tourist interest fencing, park fencing and so on.

Flat razor wire

Flat razor wire is made of carbon steel or stainless steel, which has good hardness, rigidity, and longer service life. It is transformed from the single coil concertina wire. We can also intersect various rolls of flattened single coil concertina wire and then fasten them with clips or tie wires. It can be used individually or combined with other fences to form an security wall for various sites fencing.

Concertina or spiral razor wire

Concertina or spiral razor wire is a kind of common razor wire, it occupies more than 80% of the market. It's easy to install and has a good anti- theft effect, and it's widely used for border fencing, also installed on the walls for factory fencing or residence fencing. We can offer different outer diameters for customers. Generally border line fencing razor wire outer diameter is 800 or 900 mm, but civilian will choose the type of 500 mm outer diameter.

Razor Wire Fence Hole Type

1. Square Hole Size:100mmx100mm,150mmx150mm,200mmx200mm.

2. Diamond Hole Size:75mmx150mm,100mmx200mm,150mmx300mm.

Peference

number

Thickness

(mm)

Wire dia

(mm)

Barb length

(mm)

Bard width

(mm)

Bard spacing

(mm)

BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 26±1
BTO-15 0.5±0.05 2.5±0.1 18±1 15±1 33±1
BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 34±1
BTO-30 0.5±0.05 2.5±0.1 30 18 45±1
CBT-60 0.6±0.05 2.5±0.1 60±2 32±1 100±2
CBT-65 0.6±0.05 2.5±0.1 65±2 21±1 100±2

Barbed Tape Wire Specification
Loop Outside Diameter No. of Loops Standard Length per Coil Type Notes
450mm 33 7-8M CBT-60.65 Single coil
500mm 56 12-13M CBT-60.65 Single coil
700mm 56 13-14M CBT-60.65 Single coil
960mm 56 14-15M CBT-60.65 Single coil
450mm 56 8-9m(3 CLIPS) BTO-10.12.18.22.28.30 Cross type
500mm 56 9-10M (3 CLIPS) BTO-10.12.18.22.28.30 Cross type
600mm 56 10-11M(3 CLIPS) BTO-10.12.18.22.28.30 Cross type
600mm 56 8-10M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
700mm 56 10-12M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
800mm 56 11-13M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
900mm 56 12-14M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
960mm 56 13-15M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type
980mm 56 14-16M (5 CLIPS) BTO-10.12.18.22.28.30 Cross type

Razor Wire Character

Strong Protection;
Easy installation;
Use a long time

Razor Wire Usage

1. Concertina Razor wire is widely used to manufacture the wire fence for a fencing system or security system.
2.

Concertina Razor wire is applicable in military field,airports fencing,prisons protection,detension houses, government buildings and other national security facilities.

3. Concertina Razor wire can be installed in the form of barbed tape wire or concertina coil to walls or fencing.

Bto30 HDG Spiral Razor Wire Concertina CE Certified


Product Tags:

Bto30 Spiral Razor Wire



Bto30 Razor Wire Concertina



HDG Spiral Razor Wire


Quality Bto30 HDG Spiral Razor Wire Concertina CE Certified wholesale

Bto30 HDG Spiral Razor Wire Concertina CE Certified Images
