6 Ft. X 50 Ft. Galvanized Steel Chain Link Mesh Fencing Corrosion Resistance 11.5 Gauge

AN PING XI RUN METAL MESH CO.,LTD
Contact Now

6 Ft. X 50 Ft. Galvanized Steel Chain Link Mesh Fencing Corrosion Resistance 11.5 Gauge

Brand Name : XR

Model Number : CLF-002

Place of Origin : CHINA

MOQ : 1 Roll

Price : Negotiation

Payment Terms : D/A, L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability : 20000 Square meters one month

Delivery Time : 7-12 days after get your payment

Packaging Details : 1.chain link mesh fence fabric,there is on the pallet for the roll 2.Base on the metal pallet (plastic film on around,to keep the base clean) 3.Tie wire and fittings are in the small cartons

Certification : SGS

Primary material : Steel

Color : Silver

Finished : Hot dip galvanized/electro GI

Warranty : 5-10 years limited

Advantage : Easy install

Used : For chain link fence

Post : Normally round

Application : Park,garden,sport field

Mesh opening : 50*50mm,60*60mm,75*75mm

Feature : Eco Friendly

Contact Now

6 ft. x 50 ft. 11.5-Gauge Galvanized Steel Chain Link Mesh Fence Fabric

Chain Link Fence Fabric Description

When building a privacy fence for your home or business, the Galvanized Steel Chain Link Fabric offers the perfect solution. Stretching 50 ft. L, this chain link fencing is made of 11.5-Gauge steel that has been galvanized before weaving to eliminate sharp surfaces and burrs that could cut or scrape. with a 2-3/8 in. mesh opening size, you can easily see through the fence while deterring intruders and small animals from entering the property.

Intruduction of 11.5Gauge galvanized chan link mesh fence fabric

Chain link type Woven Material Metal
Color Family Silver Product weight 108.2lb
Features Galvanized Returnable 90-days
Gauge 11.5

Warranty:

Warranty Depend on your material

Chain Link Fence Fabric Assembly Instruction:

1. Make a drawing of your fence in the space

Use chart below to determine exact number of terminal and line posts you will need based on your final layout measurements.

2. Measure the size

3. Install Fittings to Terminal Posts

Review the Material Check List on reverse side for descriptions and number of fittings required. After concrete footings have hardened, slip the tension bands over terminal posts making sure they are evenly spaced. The long, flat surface should face the outside of the fence. Carefully add brace bands making sure not to bend or distort. Bolt heads should be on the outside of the fence and threaded ends inside. Fit all post caps.

4. Install the top rails

Place an eye top fitting on the end of each line post. Flat side should be toward outside of the fence. Insert one length of top rail pipe through an eye top nearest a terminal post. Insert a rail end on the top rail and attach to terminal post with a brace band. Fasten with a 5/16” x 1-1/4” carriage bolt. Continue to join lengths of top rail by forcing swedged (or crimped) ends of top rail together through eye tops. (If joining non-swedged top rail sections, sleeves can be used as pictured below). When next terminal post is reached, measure and cut the top rail to fit tightly between the last length of top rail and the rail end fastened to the brace band on the terminal post. Fasten with a carriage bolt.

5. Affix and Stretch Chain Link Fabric

6. Hang Gates

6 Ft. X 50 Ft. Galvanized Steel Chain Link Mesh Fencing Corrosion Resistance 11.5 Gauge

Chain Link Fence Fabric Advantages

1. Galvanized to provide strength and superior corrosion resistance

2. Knuckled (bent over) on the top and bottom of the fabric to help eliminate sharp edges

3. Easy to install and maintenance-free

4.A nti-climb mesh infill

Chain Link Fence Fabric FAQ

Q:Can you add or aplice fabric together to make it longer?

A:From an end of the fabric,remove a strand of wire,join the two sections together and wind the removed wire down through the ends,in a corkscrew manner.

Note:a second strand of wire may have to be removed in order to mesh properly.

Q:Does the fabric come in different colors?

A:The chain link fabric come in black,green and white pvc coating. Check with your local store to see if your color is in stock or could special ordered.

.
