SS304 Child Playground 50m Length Steel Rope Mesh Diamond Hole Shaped

Brand Name : XR

Model Number : WRM

Certification : CE

Place of Origin : CHINA

MOQ : 5 Square Meters

Price : Negotiated

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 500 Square Meters Per Week

Delivery Time : 7-10 Days After Get The Payment

Packaging Details : Package film for each piece,Several pieces packed in 1 carton

Product Name : Wire Rope Mesh Fence

Cable Net Diameter : 2.0Mm

Feature : Handwoven

Material : SS304, SS316, SS316L

Mesh Eye Size : 70x120Mm

Mesh Type : Ferrule Wire Rope Mesh

Length : Customized

Shipping : By Air Or By Express(DHL,TNT,EMS,FedEx)

Contact Now

Child Playground Safe Wire Rope Mesh Netting 50 M Length Diamond Hole Shaped

Product Information

The stainless steel rope mesh is manufactured using a unique hand-woven interlocking technique from standard 7” x 7” and 7" x 19" ,stainless steel cable to create diamond openings from 1” through 4”.

Product Technique Parameter

Cable diameter		Mesh opening size		Nominal break
inch	mm	inch	mm	lbs.
1/8	3.2	4x4	102x102	1600
1/8	3.2	3x3	76x76	1600
1/8	3.2	2x2	51x51	1600
3/32	2.4	4x4	102x102	920
3/32	2.4	3x3	76x76	920
3/32	2.4	2x2	51x51	920
5/64	2.0	3x3	76x76	676
5/64	2.0	2x2	51x51	676
5/64	2.0	1-1/2x 1-1/2	38x38	676
1/16	1.6	3x3	76x76	480
1/16	1.6	2x2	51x51	480
1/16	1.6	1-1/2x 1-1/2	38x38	480
1/16	1.6	1x1	25.4x25.4	480
3/64	1.2	1-1/2x 1-1/2	38x38	270
3/64	1.2	1x1	25.4x25.4	270
3/64	1.2	4/5x4/5	20x20	270

Product characters

1.pattern design support according to the application

2. frame design support according to the installation

3. surface treatments support , include PVDF, PVD, Spraying.

4. supply install accessories, include screw, wall anchor, track, bolt and others

5.Material: stainless steel, copper, bronze, brass, aluminum, aluminum alloy, etc.

6.Weave type: plain weave, twill weave, dutch weave, plain dutch weave, twill dutch weave, unique woven method, etc

Product Usages

Our stainless steel architectural rope mesh is an extremely strong containment netting

suitable for smaller mammals,

primates and large birds.

Individual mesh knots are double fastened and the netting does not have to be installed under tension.

Product Tags:

50m length steel rope mesh

diamond hole steel rope mesh

SS304 steel rope mesh
