Balcony / Car Park Protection 7x7 Stainless Steel Architectural Mesh

AN PING XI RUN METAL MESH CO.,LTD
Contact Now

Balcony / Car Park Protection 7x7 Stainless Steel Architectural Mesh

  • 1
  • 2

Brand Name : XR

Model Number : WRM

Certification : CE

Place of Origin : CHINA

MOQ : 5 Square Meters

Price : Negotiated

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 500 Square Meters Per Week

Delivery Time : 7-10 Days After Get The Payment

Packaging Details : Package film for each piece,Several pieces packed in 1 carton

Product Name : Wire Rope Mesh Fence

Cable Net Diameter : 2.0Mm

Feature : Handwoven

Material : SS304, SS316, SS316L

Mesh Eye Size : 70x120Mm

Mesh Type : Ferrule Wire Rope Mesh

Length : Customized

Shipping : By Air Or By Express(DHL,TNT,EMS,FedEx)

Contact Now

High Durability Stainless Steel Architectural Mesh For Balcony / Car Park Protection

Product Description

The stainless steel rope mesh is manufactured using a unique hand-woven interlocking technique from standard 7” x 7” and 7" x 19" ,stainless steel cable to create diamond openings from 1” through 4”.

Product Specification

1. Material : Stainless steel 304,304L,316,306L etc.
2. Ferrules Material : Tinned-copper,Nickel-plated copper, Stainless steel etc.
3. Cable construction and Diameter : 7x7 (Dia.: 1.2 - 2.5mm), 7x19 (Dia.: 3.0 - 4.0mm)

Material Stainless steel Opening Area 60.6%
Cable Diameter 2.75mm×3 Mesh Thickness 10mm
Cable Pitch 68mm Surface free oil
Rod Diameter 4.5mm Max High 100m
Rod Pitch 14.5mm Max Wide 6000mm
Weight 10.9kgs/m2 Application Interior/exterior

Material Stainless steel Opening Area 62.5%
Cable Diameter 2.75mm×2mm Mesh Thickness 9.5mm
Cable Pitch 40mm Surface free oil
Rod Diameter 4mm Max High 6000mm
Rod Pitch 14.5mm Max Wide 60000mm
Weight 9.41kgs/m2 Application Interior/exterior

Material Stainless steel Opening Area 44%
Cable Diameter 1mm×4 Mesh Thickness 3.5mm
Cable Pitch 36mm Surface free oil
Rod Diameter 2mm Max High 6000mm
Rod Pitch 4mm Max Wide 120m
Weight 6.8kgs/m2 Application Interior/exterior

Material Stainless steel Opening Area 56.9%
Cable Diameter 2.5mm×5 Mesh Thickness 7mm
Cable Pitch 80mm Surface free oil
Rod Diameter 2mm Max High 100m
Rod Pitch 6mm Max Wide 6000mm
Weight 6.58kgs/m2 Application Interior/exterior

Product Usages

Our stainless steel architectural rope mesh is an extremely strong containment netting suitable for smaller mammals, primates and large birds. Individual mesh knots are double fastened and the netting does not have to be installed under tension.

Product Benifits

316 "marine grade" stainless steel

nnovative, highly durable product
Black anodised or galvanised finish options

Great prices

Professional, friendly service

Pliable, high strength mesh system

Product characters

1.pattern design support according to the application
2. frame design support according to the installation
3. surface treatments support , include PVDF, PVD, Spraying.
4. supply install accessories, include screw, wall anchor, track, bolt and others
5.Material: stainless steel, copper, bronze, brass, aluminum, aluminum alloy, etc.
6.Weave type: plain weave, twill weave, dutch weave, plain dutch weave, twill dutch weave, unique woven method, etc
