2.0mm 304 316 Handwoven Stainless Steel Wire Rope Mesh

Product Categories
AN PING XI RUN METAL MESH CO.,LTD
Contact Now

2.0mm 304 316 Handwoven Stainless Steel Wire Rope Mesh

  • 1
  • 2

Brand Name : XR

Model Number : WRM

Certification : CE

Place of Origin : CHINA

MOQ : 5 Square Meters

Price : Negotiated

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 500 Square Meters Per Week

Delivery Time : 7-10 Days After Get The Payment

Packaging Details : Package film for each piece,Several pieces packed in 1 carton

Product Name : Wire Rope Mesh Fence

Feature : Handwoven

Material : SS304, SS316, SS316L

Mesh Eye Size : 70x120Mm

Cable Net Diameter : 2.0Mm

Mesh Type : Ferrule Wire Rope Mesh

Length : Customized

Shipping : By Air Or By Express(DHL,TNT,EMS,FedEx)

Contact Now

304 316 Rope Stainless Steel Woven Wire Mesh Fence For Protection Zoo / School / Farm

Wire Rope Mesh Fence Product Description

Stainless steel wire rope protection mesh is manufactured from high-grade stainless steel cables of material AISI316.It is widely used in the decoration, construction and transformation of animal fences and gardens in zoos, wildlife parks, marine parks and other similar environments. In addition, the stainless steel rope mesh is also suitable for sports, acrobatics, home decoration, architectural decoration and other fields.
Stainless steel wire rope mesh safety mesh products have various specifications suitable for different installation environment. We will recommend the wire rope diameter, mesh opening and installation suggestions suitable for each installation place according to the different requirements of customers.The product always does justice to the individual requirements.

Wire Rope Mesh Fence Product Details

Material Stainless Steel 304 316 316L
Wire Rope Diameter 1.2mm,1.5mm,1.6mm,2.0mm,2.4mm.3.2mm,4.0mm are popular(customized)
Mesh Opeing Size 1-1/2''x1-1/2'', 2''x2'',3''x3'',4''x4'',4.75''x4.75'' are popular(customized)
Wire Rope Mesh Quality Geade A
Usage Safety mesh,architectural mesh,zoo Mesh,Animal Enclosure,decoration mesh etc.
Rope Construction 7x7,7x19,1x19


2.0mm 304 316 Handwoven Stainless Steel Wire Rope Mesh

Wire Rope Mesh Fence Available Specifications

Stainless Steel Wire Rope Mesh Safety Protection Mesh
Rope Diameter 1.2mm 1.6mm 2.0mm 2.4mm 3.2mm
Structure 7x7 7x7 7x7 7x7 7x19
Single Wire TS(N/mm2) 1770 1770 1770 1770 1570

Wire Rope Mesh Fence Parameters

Hole Size
(Opening)

1.2MM(3/64)
(7 x 7 )

1.6MM(1/16)
(7 x 7 )

2.0MM(5/64)
(7 x 7 )

2.4MM(3/32)
(7 x 7 )

3.2MM(1/8)
(7 x 19 )
20 x 35mm F-1235
25 x 42mm F-1225 F-1625
30 x 52mm F-1230 F-1630 F-2030
35 x 60mm F-1235 F-1635 F-2035
38 x 66mm F-1238 F-1638 F-2038 F-2438
40 x 69mm F-1240 F-1640 F-2040 F-2440 F-3040
50 x 86mm F-1250 F-1650 F-2050 F-2450 F-3050
60 x 104mm F-1260 F-1660 F-2060 F-2460 F-3060
70 x 120mm F-1270 F-1670 F-2070 F-2470 F-3070
76 x 131mm F-1276 F-1676 F-2076 F-2476 F-3076
80 x 138mm F-1280 F-1680 F-2080 F-2480 F-3080
90 x 154mm F-1290 F-1690 F-2090 F-2490 F-3090
100 x 173mm F-12100 F-16100 F-20100 F-24100 F-30100
120 x 206mm F-12120 F-16120 F-20120 F-24120 F-30120


Stainless steel 304,304L,316,306L etc.

SS304 (%) C:≤0.07, Si :≤1.0, Mn :≤2.0, Cr :17.0-19.0, Ni :8.0-11.0, S :≤0.03, P :≤0.035
SS316 (%) C:≤0.08, Si:≤1.00, Mn:≤2.00, P≤:0.035, S:≤0.03, Ni:10.0-14.0, Cr:16.0-18.5
SS316L (%)C:≤0.03, Si:≤1.00, Mn:≤2.00, P:≤0.045, S:≤0.030, Cr:16.0～18.0, Ni:12.0～15.0


Stainless Steel Wire Rope Mesh is custom manufactured to in widths and lengths to suit your architectural application. Finished diamond mesh style when it is stretched at 60 degree angle ; Diagonal and irregular shapes can also be supplied. Mesh can be applied in either a vertical or horizontal direction, again dependent on the balustrade or railing design and the required aesthetics.

Stainless Steel Rope Mesh Fence Benifits

316 "marine grade" stainless steel
Innovative, highly durable product
Black anodised or galvanised finish options
Great prices
Professional, friendly service
Pliable, high strength mesh system


2.0mm 304 316 Handwoven Stainless Steel Wire Rope Mesh2.0mm 304 316 Handwoven Stainless Steel Wire Rope Mesh
2.0mm 304 316 Handwoven Stainless Steel Wire Rope Mesh
