Chain Link Fencing 8FT Hot Dipped Galvanized For Farm/ Basketball Court
Description Of Chain Link Fencing
Chain Link Fence/Chain Link Wire Mesh Chain link fence is made of galvanized or pvc coated iron wire, to fix with posts, brace and fittings to build a chain link fence system in the park, tennis court, airport and other places. Also can be used for animal breeding.
Product Name:Chain Link Fence
Material:Steel
Color:Silver,Green,customized
Mesh Opening 60x60mm,50x50mm,75x75mm
Wire Diameter:1-7mm
Length:10m,20m,30m,40m etc
Height:4,5,6,8ft
Specification Of Chain Link Fencing
| Recommended use | Mesh sizes available (inch) | Nominal coated wire size (gauge) | Height of fence fabric (inch) |
| Industrial/commercial | 2" | 6 | 36" – 144" |
| 2" | 9 | 36" – 144" |
| 2" | 10 | 36" – 144" |
| 2" | 11 | 36" – 144" |
| Industrial/security | 1" | 6 | 36" – 144" |
| 1" | 9 | 36" – 144" |
| Security | 1" | 9 | 36" – 144" |
| 1" | 11 | 36" – 144" |
| 3/4" | 9 | 36" – 144" |
| 3/4" | 11 | 36" – 144" |
| 5/8" | 9 | 36" – 144" |
| 5/8" | 11 | 36" – 144" |
| 1/2" | 9 | 36" – 144" |
| 1/2" | 11 | 36" – 144" |
| 3/8" | 10 | 36" – 144" |
| 3/8" | 11 | 36" – 144" |
| Tennis Court | 1-3/4" | 9 | 36" – 144" |
| 1-3/4" | 11 | 36" – 144" |
| Mesh | Wire Thickness | Surface Treatment | Panel Width | Height |
| 40x40mm 50x50mm 60x60mm 65x65mm 75x75mm | 2.0mm - 4.8mm | Galvanized and PVC coated Or Hot dipped galvanized | 10m 15m 18m 20m 25m 30m | 1200mm |
| 1500mm |
| 1800mm |
| 2000mm |
| 2100mm |
| 2400mm |
| 2500mm |
| 3000mm |
| 3600mm |
| Profile | Wall Thickness | Surface Treatment | Length | Rain hat |
| Φ60 | 1.50mm - 5.20mm | Galvanized and Electrostatic polyester powder coated or hot dipped galvanized | On the basis of panel height | Metal |
| Φ75 |
Applications Of Chain Link Fence Mesh
Commercial/recreational
-
Hospital
-
Airports
-
Tennis courts
-
Golf courses
-
Athletic fields
Chain Link Fence - Commercial Fence Applications
42" - 60" Chain Link Fence
Posts: 2 3/8" O.D. Terminal/End/Corner; 1 7/8" O.D. Line
Fabric: 9GA x 2" Mesh
Top rail: 1 5/8" O.D.
Middle Rail: 1 5/8" O.D
Bottom Rail: 1 5/8" O.D
Post Caps: Dome Style
Footings: Terminal posts 42" deep x 12"; Line Posts 36" x 10";
72" - 84" Chain Link Fence
Posts: 2 7/8" O.D. Terminal/End/Corner; 2 3/8" O.D. Line
Fabric: 9GA x 2" Mesh
Top rail: 1 5/8" O.D.
Middle Rail: 1 5/8" O.D
Bottom Rail: 1 5/8" O.D
Post Caps: Dome Style
Footings: Terminal posts 48" deep x 12"; Line Posts 42" x 10";
96" - 120" Chain Link Fence
Posts: 4" O.D. Terminal/End/Corner; 2 7/8" O.D. Line
Fabric: 9GA x 2" Mesh
Top rail: 1 5/8" O.D.
Middle Rail: 1 5/8" O.D
Bottom Rail: 1 5/8" O.D
Post Caps: Dome Style
Footings: Terminal posts 48" deep x 14"; Line Posts 48" x 12"
