Square Hole 304 Wire 5 Micron Stainless Steel Mesh

AN PING XI RUN METAL MESH CO.,LTD
Contact Now

Square Hole 304 Wire 5 Micron Stainless Steel Mesh

  • 1
  • 2

Brand Name : XR

Model Number : FS-0340

Certification : ISO9001

Place of Origin : CHINA

MOQ : 1 Roll

Price : Be Negotiation

Payment Terms : T/T, Western Union, MoneyGram, L/C

Supply Ability : 30000 Pcs Per Week

Delivery Time : 5-8 Days After Get The Payment

Packaging Details : Plastic Film And Then Wooden Box

Product Name : Screen Plastic Extrude Recycling Filter Mesh

Type : Extruder Screen Packs

Material : Stainless Steel 304

Hole Shape : Square

Packs Diameter : 20 mm - 900 mm

Characteristics : Precise Fitting Filter Elements

Benifits : Corrosion Resistance

Product Length : 30M

Contact Now

Square Hole Mesh Stainless Steel 304 Wire Mesh For Screen Plastic Extrude Recycling Filter Mesh

Plastic Extrude Recycling Filter Mesh Description

This pack screen filter is designed to keep away mixing of foreign particles in finally equipped extrusion product. Also called polymer filter or melt filter screen. Extruder Screen Mesh packs are mainly made from high quality SS 316, SS304L meshes ranging from 4 mesh to 500 mesh up to 5 microns, and used for Plastic and Rubber Industry.

Plastic Extrude Recycling Filter Mesh Parameters

Material
black wire cloth, stainless steel wire mesh, monel 400 mesh, brass mesh, copper mesh
Filter Pack Diameter
20mm-900mm
Filtration Rate
5um-1000um
Mesh Type
woven wire mesh, fine filter mesh, coarse mesh
Weave Type
plain weave, dutch weave, twill weave
Filter Layer
single layer or multi-layers
Filter rim-binder, welded with frame
none
spot welds
stainless steel, aluminium, copper, galvanized, rubber etc
Shape
circular, oval-shaped, hoop, rectangular, square, kindney shape , ring-shaped, cylindricals, cones, bowl, waist,elliptical, disc
Welding
argon ARC welding, spot welding, laser welding, plasma welding, edge covering and sintered

Plastic Extrude Recycling Filter Mesh Kind


1.Extruder screen filter disc,

2.Circular screen,

3.Multilayer extruder screen packs.

4.Spot welded and with or without aluminum frame Layer:

5.Single layer or multilayer.

Plastic Extrude Recycling Filter Mesh Technique

Standard Extruder Screen Filter Media Specification
SS Mesh
Wire Dia. mm
Aperture Size mm
Open Area
10 X 10
0.711
1.829 MM
51.8
14 X 14
0.457
1.357 MM
55.9
16 X 16
0.457
1.131 MM
50.7
20 X 20
0.457
0.813 MM
41.0
24 X 24
0.376
0.682 MM
41.4
30 X 30
0.376
0.531 MM
34.2
30 X 30
0.310
0.536 MM
40.0
40 X 40
0.274
0.361 MM
32.3
50 X 50
0.193
0.335 MM
43.6
60 X 60
0.193
0.230 MM
29.8
80 X 80
0.122
0.196 MM
37.9
100 X 100
0.102
0.152 MM
36.0
120 X 120
0.091
0.120 MM
31.8
150 X 150
0.071
0.088 MM
29.6
200 X 200
0.050
0.077 MM
36.76
300 X 300
0.040
0.045 MM
27.83
325 X 325
0.035
0.043 MM
30.49
400 X 400
0.028
0.036 MM
31.25

Plastic Extrude Recycling Filter Mesh Features

1.Compressive and durable

2.High finish

3.Stable Performance

4.Support Customization

Wire Mesh Extruder Screen Packs Application

it is widely used in the field of petroleum,,

chemical industry,

chemical fiber,

rubber,

metallurgy,

medicine and food.

It also has different sizes and bears

the advantages of acid-resistance, alkali-resistcance, hot-resistance,

high tensile strength, wear-resistcance, etc.
