Brand Name : XR
Certification : SGS
Place of Origin : CHINA
MOQ : 1 m²
Price : Nagociation
Payment Terms : L/C, T/T, Western Union, MoneyGram
Supply Ability : 50000 m² per week
Delivery Time : 7 days after payment
Packaging Details : in box
Product Name : Stainless Steel Wire Rope Mesh
Processing Service : Bending, Welding, Decoiling, Cutting, Punching
Weave type : Buckle/Weave
Color : Black/Silver/Gold
Feature : high strength,hign tensile,flexible
Opening size : 25*25mm to 300*300mm
Material : STAINLESS STEEL WIRE, SUS304,304L,316,316L
Application : Hotel, Balcony, Deck, Porch, Stair, Terrace, Veranda, Lobby, Mall
Stainless steel 304/316 2.0mm Dia. hand woven wire rope mesh
WIRE ROPE MESH (also called cable mesh) made form high quality stainless steel wire rope, with the features of extremely anti-corrosion and resistant to UV rays, has a long lifespan in the harsh environments. And its largest benefit is particular resilience and flexibility. Our rope mesh may in knotted, ferrule type, woven square, or square mesh with cruciate/cross clamps. They are all favored by fashion architects.
Cable diameter | Mesh opening size | Nominal break | ||
inch | mm | inch | mm | lbs. |
1/8 | 3.2 | 4x4 | 102x102 | 1600 |
1/8 | 3.2 | 3x3 | 76x76 | 1600 |
1/8 | 3.2 | 2x2 | 51x51 | 1600 |
3/32 | 2.4 | 4x4 | 102x102 | 920 |
3/32 | 2.4 | 3x3 | 76x76 | 920 |
3/32 | 2.4 | 2x2 | 51x51 | 920 |
5/64 | 2.0 | 3x3 | 76x76 | 676 |
5/64 | 2.0 | 2x2 | 51x51 | 676 |
5/64 | 2.0 | 1-1/2x 1-1/2 | 38x38 | 676 |
1/16 | 1.6 | 3x3 | 76x76 | 480 |
1/16 | 1.6 | 2x2 | 51x51 | 480 |
1/16 | 1.6 | 1-1/2x 1-1/2 | 38x38 | 480 |
1/16 | 1.6 | 1x1 | 25.4x25.4 | 480 |
3/64 | 1.2 | 1-1/2x 1-1/2 | 38x38 | 270 |
3/64 | 1.2 | 1x1 | 25.4x25.4 | 270 |
3/64 | 1.2 | 4/5x4/5 | 20x20 | 270 |
Main Feature:
1.The mesh is clipped to the cable.
2.The hole size and diameter can be modified.
3.It can be made to customer orders and statically tested – especially suitable for facades.
4.High strength,strong toughness,free-angles curving and fold,easy for transportation and installment.
5.Anti-corrosive,resist the rust,can be repeated use.
6.Resists chewing by rodents and other pests (tensile strength approximately 100-110,000 PSI)
7.This product can bear the heavy snow and the gale very much.
8.Without toxic material,safety,environmental protection.
![]() |
304/316 2.0mm Dia Stainless Steel Wire Rope Mesh Hand Woven Images |
